High Performance Computing Server - Dual Intel Xeon Scalable Processor Series, 2U Server, 8x GPU Cards
Buy with confidence knowing all Broadberry CyberServe rack servers are backed up by our 3 year warranty, with further warranty upgrade options available.
The Broadberry range of CyberServe® rackmount are trusted as the server of choice for thousands of companies from SMBs to enterprise's across the globe.
GPU SuperComputing servers offer massive processing power and HPC performance, considerably accelerating applications.
This system can be configured with SATA drives for cost-effective 12gb/s storage.
The CyberServe Xeon SP2-G291-281 GPU Server boasts high density storage and ultimate energy efficiency, catering for up to 8x High-Performance 2.5" SSD or Hard Drives
Designed for the most demanding tasks, the dual socket range of CyberServe Xeon SP® servers support the latest Intel Xeon® processor Scalable series
Powered by the revolutionary Intel Xeon SP processor range, CyberServe Xeon SP servers deliver massive improvements in every metric over the previous generation of Xeon E7 and E5 processors.
The Broadberry CyberServe Xeon SP® range has been built from the ground up for private / hybrid cloud environments, clustering, virtualised infrastructure and database management.
The Broadberry CyberServe Xeon SP® range has a completely redesigned QPI system, producing up to 21% improvement in data efficiency as well as a 50% reduction in idle power.
All Broadberry CyberServe Xeon SP® rack servers are compatible with iPMI functionality, enabling complete control and management of your server through IP.
Boasting Intel Integrated I/0 on the processor, Broadberry CyberServe Xeon SP® servers accelerate data availability to the processing cores, reducing latency by up to 30%.
Intel Advanced Vector Extensions 512, the latest x86 vector instruction set with up to two fused-multiply add units and other optimisations, accelerates performance for the most demanding computational tasks.
Improving performance across applications and platforms, Intel QAT enhances security and compression performance in cloud, networking, big data, and storage applications.
The CyberServe Xeon SP® range replaces InfiniBand technology with a newer, more advanced interconnect called Omni-Path, allowing for 100Gbps bandwidth with no loss of PCIe lanes.
The CyberServe Xeon SP2-G291-281 GPU Server has been carefully crafted to ensure full compatibility with VMWare, making it an ideal choice for use as a virtualisation server
The CyberServe Xeon SP2-G291-281 GPU Server is configurable with a hot-swap redundant power supply, meaning minimal down-time for mission critical applications.
| Dimensions (WxHxD, mm) | 2U 448 x 87.5 x 800 |
| Motherboard | MG50-G20 |
| CPU | Intel Xeon E5-2600 V3 processors Intel Xeon E5-2600 V4 processors NOTE: If only 1 CPU is installed, some PCIe, memory, network or I/O functions might be unavailable. |
| Socket | 2 x LGA 2011-3 Mounting pitch: narrow ILM (56x94mm) Max. length of M4 screw threads: 3.7mm Screws longer than 3.7mm might damage the motherboard |
| Chipset | Intel C612 |
| Memory | 24 x DIMM slots DDR4 memory supported only Quad channel memory architecture RDIMM modules up to 32GB supported LRDIMM modules up to 64GB supported 3DS LRDIMM modules up to 128GB supported 1.2V modules: 1600/1866/2133/2400 MHz |
| LAN | 2 x 10GbE SFP+ ports (Intel 82599ES) 1 x 10/100/1000 management LAN 2 x QSFP+ ports (supporting 56Gb/s FDR InfiniBand or 40GbE) card (Mellanox MT27508A1-FCCR-FV) in option (GC-MNXE2) 2 x 10Gb/s SFP+ LAN card (Mellanox MT27518A1-FCCR-XE) in option (GC-MNXE20) |
| Video | Integrated in Aspeed AST2400 2D Video Graphic Adapter with PCIe bus interface 1920x1200@60Hz 32bpp |
| Storage | 8 x 2.5" hot-swappable HDD/SSD bays |
| SAS | GC-MSLZ1 expansion card in option:
|
| SATA | 10 x SATA III 6Gb/s ports |
| RAID | Intel SATA RAID 0/1/5/10 |
| Peripheral Drives | - |
| Expansion Slots | 8 x PCIe x16 (Gen3 x16 bus) connectors supporting:
1 x PCIe x16 (Gen3 x8 bus) connector 1 x Proprietary PCIe x8 (Gen3 x8 bus) mezzanine connector |
| Front I/O | 1 x Power button with LED 1 x ID button with LED 2 x LAN activity LEDs 1 x HDD activity LED 1 x System status LED 1 x Reset button |
| Rear I/O | 2 x USB 3.0 1 x VGA 1 x Serial 2 x SFP+ 1 x RJ45 1 x Power button with LED 1 x ID button with LED 1 x Reset button 1 x NMI button 1 x System status LED |
| Internal I/O | 1 x 18-pin power connector 1 x 14-pin power connector 2 x 8-pin power connectors 2 x 4-pin power connectors 10 x SATA III 6Gb/s ports 1 x USB 3.0 header 1 x USB 2.0 header 1 x TPM header 1 x HDD back plane board header 1 x 12-pin front panel header 1 x 23-pin front panel header 1 x JTAG header 2 x SATA SGPIO headers 1 x Front VGA header 1 x Serial header 1 x IPMB connector 1 x P12V standby connector 1 x PMBus selection jumper 1 x Clear CMOS jumper 1 x LT debug jumper |
| Backplane I/O | 8 x SAS/SATA ports |
| TPM | 1 x TPM header |
| Power Supply | 2 x 2000W redundant PSU 80 PLUS Platinum AC input: - 1000W: 100-120V/ 12.5-10.5A, 50-60Hz - 1800W: 200-220V/ 10-9.5A, 50-60Hz - 1980W: 220-230V/ 10-9.8A, 50-60Hz - 2000W: 230-240V/ 10-9.8A, 50-60Hz DC output: - 11000W@100-120V - 1800W@200-220V - 1980W@220-230V - 2000W@200-240V |
| System Management | Aspeed AST2400 management controller Avocent MergePoint IPMI 2.0 web interface:
|
| OS Supported | Windows Server 2008 R2 (x64) Windows Server 2012 (x64) Windows Server 2012 R2 (x64) Red Hat Enterprise Linux 6.7 (x86/x64) Red Hat Enterprise Linux 7.2 (x64) SUSE Linux Enterprise Server 11.4 (x86/x64) SUSE Linux Enterprise Server 12 (x64) Ubuntu 12.04 LTS (x86/x64) Ubuntu 14.04 LTS (x86/x64) VMware ESXi 5.1 U2 VMware ESXi 5.5 U2 VMware ESXi 6.0 U1 |
| Weight | 31 kg (full packaging) |
| System Fans | 8 x 80x80x38mm (15000rpm) |
| Operating Properties | Operating temperature: 10C to 35C Operating humidity: 8%-80% (non-condensing) Non-operating temperature: -40C to 60C Non-operating humidity: 20%-95% (non-condensing) |
| Part Numbers | Barebone with rail kit: 6NG250G51MR-00 Tool-less rail kit: 25HB2-A86100-K0R Power supply: 25EP0-220000-C2S NVIDIA M60/K80 power cable: 25CRI-300307-B0R (in option) |
| Packaging Content | 1 x G250-G51 1 x Driver CD 2 x CPU heat sinks 1 x Rail Kit |
The CyberServe Xeon SP2-G291-281 GPU Server is a 2U rackmount server configurable with 2x Xeon Scalable Processor Gen 2 series range of processors. Built using the latest enterprise-class server technology, the CyberServe Xeon SP2-G291-281 GPU Server has 8x 2.5" SATA and 12Gb/s SAS Hot-Swap Drives and is ideal for those requiring a combination of high performance and density with its 24x DDR4 ECC Registered memory banks providing up to GB of high-performance server memory. The CyberServe Xeon SP2-G291-281 GPU Server boasts as just a few of its core features.
The added benefit of hot-swap hard drives means that the CyberServe Xeon SP2-G291-281 GPU Server can have any of its 8 hot-swap hard drives removed during maintenance whilst the system is running completely un-interrupted. The added benefit of hot-swap hard drives means that the CyberServe Xeon SP2-G291-281 GPU Server can have any of its 8 hot-swap hard drives removed during maintenance whilst the system is running completely un-interrupted.Storage Technology
The CyberServe Xeon SP2-G291-281 GPU Server supports 8x 2.5" desktop and enterprise-class SATA hard drives, which represents the best cost per GB ratio storage technology.
Originally designed and utilised in mobile applications such as laptops and notebooks, 2.5" hard drives are becoming ever increasingly used in servers due to their lower power consumption and space-saving characteristics. The added benefit of hot-swap hard drives means that the CyberServe Xeon SP2-G291-281 GPU Server can have any of its 8 hot-swap hard drives removed during maintenance whilst the system is running completely un-interrupted.Configure for your Network
The CyberServe Xeon SP2-G291-281 GPU Server’s ready to be deployed into your network environment with a wide-range of high-throughput connectivity options.
Configure the CyberServe Xeon SP2-G291-281 GPU Server to match your application I/O demands and network infrastructure with up to 2x Intel Gigabit Ethernet Adaptors , Intel 10 Gigabit Ethernet Adaptors, Qlogic Fibre Channel Adaptors, Intel 25/40/50 Gigabit Ethernet Adaptors, Mellanox ConnectX-4 Series Ethernet Adaptors.
Whether your application demands the highest networking throughput, or you’re looking for a more modest enterprise-grade networking option such as Gb/E, the CyberServe Xeon SP2-G291-281 GPU Server is totally customisable with a wide range of robust I/O connectivity options.
IPMI 2.0 & KVM over IP
Whereas most server manufacturers charge ongoing licence fees for IPMI, powerful, industry-standard server management is built in to the CyberServe Xeon SP2-G291-281 GPU Server at no extra cost.
Using the dedicated 3rd LAN port or on-board Gigabit Ethernet ports, you can take full control of the server as though you were standing in front of it through your web browser from anywhere in the world through a pre-defined IP address and password.
Check the health of the CyberServe Xeon SP2-G291-281 GPU Server components, fan speeds, temperatures, update firmware, check logs & set SMTP alerts for you pre-configure thresholds, and list the health of all your servers on one simple screen.Â
The CyberServe Xeon SP2-G291-281 GPU Server IPMI feature also allows complete Keyboard Video and Mouse (KVM) control, and send CD/DVD Images over IP to install software & operating systems remotely.
Expand with PCI-Express Expansion
Configure the CyberServe Xeon SP2-G291-281 GPU Server with up to 2x Intel Gigabit Ethernet Adaptors , Intel 10 Gigabit Ethernet Adaptors, Qlogic Fibre Channel Adaptors, Intel 25/40/50 Gigabit Ethernet Adaptors, Mellanox ConnectX-4 Series Ethernet Adaptors. With a wide range of enterprise-class PCI-Express add-on options available, the CyberServe Xeon SP2-G291-281 GPU Server is a flexible platform for a wide-range of applications.
The added benefit of hot-swap hard drives means that the CyberServe Xeon SP2-G291-281 GPU Server can have any of its 8 hot-swap hard drives removed during maintenance whilst the system is running completely un-interrupted.In today’s climate we appreciate the importance of preserving working capital yet understand that businesses still need to invest in new technology. We are delighted to inform our customers that Finance is available from just £1000 + VAT via our Strategic Partner BlueStar.
You can finance the total solution including hardware, software and installation costs and BlueStar will be happy to advise you of the most suitable package for your organisation.
BlueStar’s leasing options have enabled our customers to spread the cost of a new solution typically over a 3 year period. All payments made on a lease can be offset against taxable profits which may improve tax efficiency. Leasing also provides a flexible upgrade path allowing our customers to add further equipment to their lease throughout the term.
Finance helps to remove cash flow concerns and allows our customers to acquire the right system for their business rather than what available cash reserves dictate. Information technology is an operating cost to your business, pay for the equipment as you use it and get an immediate return on your investment.
Do you need to replace outdated equipment but don’t have the budget to purchase today?
Call us today on 020 8997 6000 to find out how leasing can work for you. Finance is subject to status and available to businesses only.
Sécurité de pointe
Nous prenons la sécurité au sérieux. Les serveurs Broadberry offrent les dernières technologies, dont le TPM, l'auto-cryptage et la certification FIPS de niveau militaire.
Un Rapport Qualité/Prix Imbattable
Broadberry offre toute une gamme de serveurs et de solutions de stockage sur mesure aux meilleures conditions.
Management facilité
Un IPMI riche en fonctionnalités avec outband management et redfish API vous permet un management et un monitoring facilités de vos systèmes Broadberry.
Service Clients
Contrairement à certains fabricants, Broadberry attribue à tous ses clients un gestionnaire de compte dédié avec un accès direct. Il n'y a pas de centres d'appels!
Montage Professionnel
Nos ingénieurs qualifiés préconfigurent votre serveur selon vos besoins et se tiennent à votre disposition par téléphone à l'arrivée de votre serveur.
3 ans de Garantie
Toutes les solutions Broadberry sont accompagnées d'une garantie complète de 3 à 5 ans, avec toute une gamme de garanties optionnelles.
Installation Facile
Des rails coulissants à clipser, un RAID préconfiguré et un système d'exploitation préinstallé ; nos ingénieurs vous garantissent une installation simple et rapide!
Standardisation
Notre approche de plateforme ouverte offre une compatibilité élevée avec votre infrastructure existante et ne vous impose pas un fournisseur.
Flexibilité
Chaque entreprise est différente. Configurez votre solution sur mesure à l'aide de notre puissant configurateur en ligne.
Evolutivité
Nos serveurs sont conçus pour évoluer avec votre entreprise, que ce soit en achetant des disques des noeuds supplémentaires.
Innovation
Depuis le premier PC Broadberry en 1989, nous avons continuellement innové et nous sommes adaptés aux nouvelles technologies émergent sur le marcké.
| Dimensions (WxHxD, mm) | 2U 448 x 87.5 x 800 |
| Motherboard | MG50-G20 |
| CPU | Intel® Xeon® E5-2600 V3 processors Intel® Xeon® E5-2600 V4 processors NOTE: If only 1 CPU is installed, some PCIe, memory, network or I/O functions might be unavailable. |
| Socket | 2 x LGA 2011-3 Mounting pitch: narrow ILM (56x94mm) Max. length of M4 screw threads: 3.7mm Screws longer than 3.7mm might damage the motherboard |
| Chipset | Intel® C612 |
| Memory | 24 x DIMM slots DDR4 memory supported only Quad channel memory architecture RDIMM modules up to 32GB supported LRDIMM modules up to 64GB supported 3DS LRDIMM modules up to 128GB supported 1.2V modules: 1600/1866/2133/2400 MHz |
| LAN | 2 x 10GbE SFP+ ports (Intel® 82599ES) 1 x 10/100/1000 management LAN 2 x QSFP+ ports (supporting 56Gb/s FDR InfiniBand or 40GbE) card (Mellanox® MT27508A1-FCCR-FV) in option (GC-MNXE2) 2 x 10Gb/s SFP+ LAN card (Mellanox® MT27518A1-FCCR-XE) in option (GC-MNXE20) |
| Video | Integrated in Aspeed® AST2400 2D Video Graphic Adapter with PCIe bus interface 1920x1200@60Hz 32bpp |
| Storage | 8 x 2.5" hot-swappable HDD/SSD bays |
| SAS | GC-MSLZ1 expansion card in option:
|
| SATA | 10 x SATA III 6Gb/s ports |
| RAID | Intel® SATA RAID 0/1/5/10 |
| Peripheral Drives | - |
| Expansion Slots | 8 x PCIe x16 (Gen3 x16 bus) connectors supporting:
1 x PCIe x16 (Gen3 x8 bus) connector 1 x Proprietary PCIe x8 (Gen3 x8 bus) mezzanine connector |
| Front I/O | 1 x Power button with LED 1 x ID button with LED 2 x LAN activity LEDs 1 x HDD activity LED 1 x System status LED 1 x Reset button |
| Rear I/O | 2 x USB 3.0 1 x VGA 1 x Serial 2 x SFP+ 1 x RJ45 1 x Power button with LED 1 x ID button with LED 1 x Reset button 1 x NMI button 1 x System status LED |
| Internal I/O | 1 x 18-pin power connector 1 x 14-pin power connector 2 x 8-pin power connectors 2 x 4-pin power connectors 10 x SATA III 6Gb/s ports 1 x USB 3.0 header 1 x USB 2.0 header 1 x TPM header 1 x HDD back plane board header 1 x 12-pin front panel header 1 x 23-pin front panel header 1 x JTAG header 2 x SATA SGPIO headers 1 x Front VGA header 1 x Serial header 1 x IPMB connector 1 x P12V standby connector 1 x PMBus selection jumper 1 x Clear CMOS jumper 1 x LT debug jumper |
| Backplane I/O | 8 x SAS/SATA ports |
| TPM | 1 x TPM header |
| Power Supply | 2 x 2000W redundant PSU 80 PLUS Platinum AC input: - 1000W: 100-120V/ 12.5-10.5A, 50-60Hz - 1800W: 200-220V/ 10-9.5A, 50-60Hz - 1980W: 220-230V/ 10-9.8A, 50-60Hz - 2000W: 230-240V/ 10-9.8A, 50-60Hz DC output: - 11000W@100-120V - 1800W@200-220V - 1980W@220-230V - 2000W@200-240V |
| System Management | Aspeed® AST2400 management controller Avocent® MergePoint IPMI 2.0 web interface:
|
| OS Supported | Windows Server 2008 R2 (x64) Windows Server 2012 (x64) Windows Server 2012 R2 (x64) Red Hat Enterprise Linux 6.7 (x86/x64) Red Hat Enterprise Linux 7.2 (x64) SUSE Linux Enterprise Server 11.4 (x86/x64) SUSE Linux Enterprise Server 12 (x64) Ubuntu 12.04 LTS (x86/x64) Ubuntu 14.04 LTS (x86/x64) VMware ESXi 5.1 U2 VMware ESXi 5.5 U2 VMware ESXi 6.0 U1 |
| Weight | 31 kg (full packaging) |
| System Fans | 8 x 80x80x38mm (15000rpm) |
| Operating Properties | Operating temperature: 10°C to 35°C Operating humidity: 8%-80% (non-condensing) Non-operating temperature: -40°C to 60°C Non-operating humidity: 20%-95% (non-condensing) |
| Part Numbers | Barebone with rail kit: 6NG250G51MR-00 Tool-less rail kit: 25HB2-A86100-K0R Power supply: 25EP0-220000-C2S NVIDIA M60/K80 power cable: 25CRI-300307-B0R (in option) |
| Packaging Content | 1 x G250-G51 1 x Driver CD 2 x CPU heat sinks 1 x Rail Kit |
The Intel Xeon Scalable Processor Family improves upon previous generation Intel Xeon E5 and E7 V4 generations in just about every metric.
 |
 |
 |
 |
|---|---|---|---|
| Entry Intel® Xeon® Bronze processors are performance optimized for small business and basic storage servers. |
Mid Intel® Xeon® Silver processors offer the hardware-enhanced performance and security required for data center compute, network, and storage optimized for mid-sized and growing IT organisations. |
High Intel® Xeon® Gold processors offer high performance, advanced reliability, and hardware-enhanced security optimized for demanding data center, hybrid-cloud compute, network, and storage workloads. |
Enterprise Intel® Xeon® Platinum processors offer the industry's best performance for mission-critical and hybrid cloud workloads, real-time analytics, machine learning, and artificial intelligence, with monumental leaps in I/O, memory, storage, and network technologies. |
| up to 8 Cores | up to 12 Cores | up to 22 Cores | up to 28 Cores |
| up to 2 Sockets | up to 2 Sockets | up to 4 Sockets | up to 8+ Sockets |
| up to 1.5TB | up to 1.5TB | up to 6TB | up to 12TB |
The CyberServe Xeon-SP range has been designed from the ground up for the latest industry advances for today's datacenter applications.
Powered by Intel Xeon Scalable Processors, the CyberServe Xeon-SP range of servers have the design flexibility to thrive across common applications and mission critical operations or to harness actionable insights from advanced real-time analytics and emerging imperatives like artificial intelligence, 5G, autonomous driving and more.
This agility enables you to seize new business opportunities from our increasingly data-fueled smart and connected world.
| Intel Xeon Processor E5-2600 v4 | Intel Xeon Scalable Processor | |
|---|---|---|
| Cores Per Socket | Up to 22 | Up to 28 |
| Threads Per Socket | Up to 44 threads | Up to 56 threads |
| Last-level Cache (LLC) | Up to 55 MB | Up to 38.5 MB (non-inclusive) |
| QPI/UPI Speed (GT/s) | 2x QPI channels @ 9.6 GT/s | Up to 3x UPI @ 10.4 GT/s |
| PCIe* Lanes /Controllers /Speed(GT/s) | 40 / 10 / PCIe 3.0 (2.5, 5. 8 (GT/s) | 48 / 12 / PCIe 3.0 (2.5, 5,8 GT/s) |
| Memory Population | 4 channels of up to 3 RDIMMs, LRDIMMs, or 3DS LRDIMMs |
6 channels of up to 2 RDIMMs, LRDIMMs, or 3DS LRDIMMs |
| Max Memory Speed | Up to 2400 | Up to 2666 |
| TDP (W) | 55W-145W | 70W-205W |
By consolidating servers onto a VMware compatible Broadberry server, you can enjoy a reduction in your IT infrastructure footprint.
The virtualisation market has grown exponentially since the mid-2000s and as has the demand for servers able to run VMware virtualisation software. While the majority of servers will be able to run VMware, these rack servers have been specially designed and then sent off for VMware ESXI 6.0 certification.
Built from the ground up for compatibility, these servers are ideal for running your virtualised IT infrastructure.These VMware certified servers are based on hardware that is enterprise-grade and industry compliant. This range servers can be configured with up to 16 cores for processing and up to 1/2 TB of memory.
NVIDIA L4 |
NVIDIA RTX6000 ADA |
NVIDIA L40S |
NVIDIA H100 |
NVIDIA GH200 |
|
|---|---|---|---|---|---|
| Application | Virtualised Desktop, Graphical and Edge Applications | High-end Design, Real-time Rendering, High-performance Compute Workflows | Multi-modal Generative AI, and Graphics and Videos Workflows | LLMs Inference, AI and Data Analytics | Generative AI, LLMs Inference, and Memory Intensive Applications |
| Architecture | Ada Lovelace | Ada Lovelace | Ada Lovelace | Hopper | Grace Hopper |
| SMs | 60 | 142 | 142 | 114 | 144 |
| CUDA Cores | 7,424 | 18,176 | 18,176 | 18,432 | 18,432 |
| Tensor Cores | 240 | 568 | 568 | 640 | 576 |
| Frequency | 795 Mhz | 915 MHz | 1,110 Mhz | 1,590 MHz | 1,830 MHz |
| FP32 TFLOPs | 30.3 | - | 91.6 | 51 | 67 |
| FP16 TFLOPs | 242 | 91.1 | 733 | 1,513 | 1,979 |
| FP8 TFLOPs | 485 | - | 1,466 | 3,026 | 3,958 |
| Cache | 48 MB | 96 MB | 48 MB | 50 MB | 60 MB |
| Max. Memory | 24 GB | 48 GB | 48 GB | 80 GB | 512 GB |
| Memory B/W | 300 GB/s | 960 GB/s | 864 GB/s | 2,000 Gb/s | 546 GB/s |
